A steam trap is an automatic valve that lets condensate and air out of a steam line and holds steam back. Condensate forms as soon as steam gives up heat, and left in the line it slows the plant and carries the risk of water hammer. The valve set the traps sit on, measured on a Bosch UL-S, read 190 °C.
Boilers/Bosch UL-S/Steam valves/This page
Mechanical. A float or an inverted bucket rides on the liquid level and opens a valve when condensate collects. Float traps discharge continuously and suit process plant with a varying load.
Thermostatic. A bellows or bimetal element responds to the temperature difference between steam and condensate that has cooled a few degrees below saturation, holding condensate back until it has given up that heat.
Thermodynamic. A single disc that closes on the velocity of flash steam under it and opens when the pressure in the chamber above falls. One moving part, and it tolerates superheat and freezing.
| Thermodynamic | Thermostatic | |
|---|---|---|
| What operates it | Velocity of flash steam under a disc | Temperature of condensate against saturation |
| Moving parts | One disc | Bellows or bimetal element |
| Discharge | Intermittent, in bursts | Intermittent, after sub-cooling |
| Suits | Steam mains, tracing, superheat | Air venting and light loads |
| Condensate held back | Little | Until it cools below saturation |
| Element | Temp °C | Area m² | Bare W | Panelled W | Surface °C |
|---|---|---|---|---|---|
| Steam valves and piping | 190 | 0.45 | 1,430 | 70 | 36 |
| Total | 0.45 | 1,430 | 70 | ≤45 |
Temperatures are FLIR readings taken on a running boiler. Areas come from the CAD model of the same machine, uplifted for bolts and irregular geometry. Losses are ISO 12241:2022 steady state. The panelled column is capped at the 45 °C touch-safe design target, assessed to EN ISO 13732-1.
At 190 °C a bare valve body sheds 3,178 W per square metre, the highest figure in our survey set.
| Surface °C | W / m² | Area surveyed m² | Where it was read |
|---|---|---|---|
| 96 | 1086 | 2.33 | Bosch UL-S front door |
| 146 | 2094 | 0.85 | Bosch burner flange |
| 190 | 3178 | 0.45 | Bosch steam valves |
Each row is one of our own surveys: the measured loss divided by the CAD area of the same surface. Nothing is interpolated. ISO 12241:2022 steady state, still air, emissivity from the FLIR survey.
A trap fails in one of two directions, and the two cost differently. A trap blowing through wastes live steam continuously. A trap blocked shut floods the line and stalls the plant it drains. A survey has to separate the two, trap by trap.
Inzonex did not meter the traps on the machine surveyed. The 190 °C and the 0.45 m² on this page are the steam valves and piping on that view, 1,430 W bare. Loss through a passing trap is a separate quantity and we publish no figure for it.
It lets condensate and air out of a steam line and holds steam back, automatically and without an operator.
Three families: mechanical (float, inverted bucket), thermostatic (bellows, bimetal) and thermodynamic (disc).
A thermodynamic trap is operated by the velocity of flash steam under a disc and discharges in bursts. A thermostatic trap is operated by temperature and holds condensate until it has cooled below saturation.
The steam valve set we measured on a Bosch UL-S read 190 °C on the FLIR, over 0.45 m²: 1,430 W bare.
No. The 190 °C reading and the 0.45 m² cover the steam valves and piping on that view. The trap set was not separately metered and we quote no figure for it.
The surveyed view this page came from, with every element on it.Open
