What is included
The flange and bellows are one selected scope, but each part is calculated with its own geometry before the results are added.
| Reference temperature | 460 °C |
| Starting quantity | 1 · enter your site count |
| Bare heat loss | 47.174 kW |
| With insulation | 1.887 kW |
| Heat retained | 45.287 kW |
| Reduction | 96% |
| Outside surface | 40.8 °C · target met |
Temperature and quantity are editable. Energy rate, installed cost and payback remain blank until entered by the operator.
Why removable insulation matters
The module can be removed to expose the metal component and fasteners, then returned to the same position. This supports inspection without destroying and rebuilding the insulation each time.
Equipment-life boundary
Lower thermal exposure and repeatable inspection can support equipment care. A fixed life-extension figure needs component material, stress, cycling, drainage and inspection history.
